M-Loc Panels

M-Loc™ is a structural roof and wall panel that can be installed directly over purlins or joists.  The M-Loc™ panel is available in 26 gauge.  This commercial panel has long served customers with lasting durability in commercial type applications.

General Specifications

  • Panel rib height: 3/4″every 6 inches
  • Panel coverage: 36″ wide
  • Panel length: 26″ to 45′ in .5″ increments
  • Tensile strength: 80,000 psi minimum
  • Substrate: Varies by option; Galvalume®
  • Gauge: 26
  • Recommended roof slope: 1:12 pitch or greater
Category:

Related Files

Testing and Approval Data

  • Fire resistance: UL790/Class A
  • Impact resistance: UL2218/Class 4-prime and select material
  • Uplift resistance: UL580/Class 90
    • Construction numbers: 39

Available Options

Thrifty Prime Kynar
MCA certification #229SMLOC #229PMLOC
26 gauge thickness .018″ nom .0185″ min .0185″ min
Tensile strength 80,000 psi minimum 80,000 psi minimum 80,000 psi minimum
Substrate Varies Galvalume® Galvalume®
Gauge 26 26 26
Coating CentralGuard® CentralGuard® Fluropon (Kynar® 500/Hylar 5000)
Primer .1-.2 mils top .2-.3 mils top .2-.3 mils top
Paint thickness .5-.6 mils top .7-.8 mils top .7-.8 mils top
Warranty 10 yr. Paint integrity 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 yr. Galvalume® substrate
Colors 10 23 1 – Copper Metallic only

Pricing

Feel free to give us a call with any questions 269 683 2723
